Nichrome 80 – Ohms Per Inch of Closed Helix

admin — Mon, 11 Jul 2011 01:46:27 +0000

Ohms per inch of closed helix

Wire Size No. B & S	Outside Diameter of Helix in Inches
Wire Size No. B & S	³/₄	⁵/₈	¹/₂	³/₈	¹/₄	⁷/₃₂	³/₁₆	⁵/₃₂	¹/₆	³/₃₂	¹/₁₆	¹/₃₂
14	.446	.365	.283	.202	.121	.101
15	.638	.523	.408	.293	.178	.148	.120
16	.895	.735	.575	.415	.255	.215	.175	.135
17	1.32	1.08	.851	.617	.383	.325	.266	.208	.150
18	1.89	1.56	1.22	.891	.559	.475	.392	.309	.226
19	2.60	2.14	1.69	1.23	.779	.665	.551	.438	.324
20	3.72	3.07	2.42	1.78	1.13	.967	.805	.644	.482
21		4.53	3.58	2.63	1.68	1.45	1.21	.971	.733	.496
22			4.98	3.67	2.36	2.03	1.70	1.37	1.05	.719
23			7.02	5.18	3.34	2.88	2.42	1.96	1.51	1.05
23			7.02	5.18	3.34	2.88	2.42	1.96	1.51	1.05
24					4.69	4.05	3.41	2.78	2.14	1.60	.865
25					6.87	5.94	5.02	4.10	3.17	2.25	1.32

Helical Coils

admin — Mon, 11 Jul 2011 01:11:24 +0000

This data has been compiled as an aid to the manufacturers of helical coils and show the approximate current in amperes required to heat the coils in the open air to the indicated temperatures under the conditions specified.

No. B & S	Diam. Inches	Temp, 400° F. Temp, 204° C.	600 316	800 427	1000 538	1200 649	1400 760	1600 871	1800 982	2000° F. 1093° C.
14	.064	5.07	7.99	11.03	14.17	17.38	21.41	25.64	30.06	34.66
15	.057	4.14	6.69	9.65	12.23	15.17	18.30	21.53	24.85	28.23
16	.051	3.34	5.29	7.33	9.45	11.62	14.62	17.83	21.25	24.86
17	.045	2.94	4.39	6.31	7.95	9.89	12.37	14.77	17.40	20.16
18	.040	2.41	3.78	5.20	6.65	8.14	10.00	11.92	13.94	16.03
19	.036	2.11	3.25	4.59	5.89	7.23	8.88	10.62	12.42	14.30
20	.032	1.56	2.53	3.56	4.64	5.77	7.15	8.60	10.13	11.71
21	.0285	1.30	2.11	2.96	3.87	4.81	6.11	7.22	8.52	9.89
22	.0253	1.12	1.74	2.39	3.03	3.69	4.74	5.89	7.13	8.46
23	.0226	.980	1.53	2.10	2.69	3.29	4.15	5.07	6.04	7.08
24	.0200	.950	1.45	1.96	2.47	3.00	3.67	4.36	5.08	5.83
25	.0179	.820	1.25	1.70	2.15	2.61	3.19	3.80	4.44	5.08
26	.0159	.660	1.04	1.44	1.86	2.28	2.76	3.26	3.77	4.29
27	.0142	.560	.862	1.17	1.48	1.80	2.19	2.60	3.02	3.46
28	.0126	.390	.663	.893	1.18	1.45	1.80	2.17	2.56	2.97
29	.0113	.310	.509	.705	.918	1.14	1.45	1.78	2.14	2.52
30	.0100	.270	.445	.623	.791	.980	1.26	1.58	1.91	2.28

.040 through .010 based on coiling on an arbor .12 diameter and stretched to twice the close wound lengths.

Current Temperature Characteristics of Nichrome (straight wire)

admin — Sun, 10 Jul 2011 20:47:38 +0000

Showing approximate amperes necessary to produce a given temperature. Applying only to straight wires stretched horizontally in free air.

No. B & S	Diam. Inches	Temp, 400° F. Temp, 204° C.	600 316	800 427	1000 538	1200 649	1400 760	1600 871	1800 982	2000° F. 1093° C.
12	.081	11.34	15.91	20.27	25.53	31.77	39.03	46.73	54.80	63.01
13	.072	9.73	13.53	17.21	21.61	26.89	33.06	39.60	46.41	53.31
14	.064	8.34	10.50	14.59	18.30	22.76	28.01	33.56	39.31	45.11
15	.057	7.15	9.78	12.38	15.50	19.26	23.73	28.44	33.30	38.17
16	.051	6.13	8.31	10.50	13.11	16.30	20.10	24.10	28.20	32.30
17	.045	5.31	7.18	9.13	11.30	13.90	16.90	20.30	23.60	27.00
18	.040	4.66	6.26	7.90	9.75	11.96	14.51	17.37	20.48	23.08
19	.036	4.09	5.46	6.84	8.41	10.30	12.45	14.87	17.78	19.73
20	.032	3.58	4.77	5.92	7.25	8.86	10.69	12.72	15.43	16.87
21	.0285	3.14	4.16	5.13	6.26	7.63	9.17	10.88	13.40	14.40
22	.0253	2.76	3.63	4.44	5.40	6.56	7.87	9.31	11.63	12.33
23	.0226	2.42	3.16	3.84	4.67	5.65	6.76	7.97	10.09	10.54
24	.020	2.12	2.76	3.32	4.01	4.86	5.80	6.82	8.76	9.01
25	.0179	1.84	2.42	2.90	3.44	4.15	4.97	5.86	6.96	7.72
26	.0159	1.58	2.09	2.52	3.00	3.61	4.31	5.06	5.97	6.63
27	.0142	1.34	1.80	2.19	2.62	3.14	3.73	4.37	5.12	5.69
28	.0126	1.18	1.55	1.90	2.28	2.73	3.23	3.77	4.39	4.88
29	.0113	1.02	1.34	1.65	1.99	2.37	2.80	3.25	3.76	4.39
30	.010	.875	1.16	1.43	1.74	2.06	2.43	2.81	3.22	3.59

.040 through .010 based on coiling on an arbor .12 diameter and stretched to twice the close wound lengths.

Size and Approximate Cold Resistances of Various Alloys for Common Wattages

admin — Wed, 06 Jul 2011 16:57:53 +0000

Watts at Operating Temperatures
	Nichrome V Ohms at 75° F.		Nichrome Ohms at 75° F.		Recommended B. & S. Sizes
	110-120 Volts	220-240 Volts	110-120 Volts	220-240 Volts	110-120 Volts	220-240 Volts
100	123.52	494.09	118.10	472.40	Max. 26-30 Min.	Max. 29-33 Min.
150	82.347	329.38	78.732	314.93	26-30	29-33
200	61.761	247.04	59.050	236.20	25-29	28-32
250	49.409	197.64	47.240	188.96	24-28	27-31
300	41.174	164.69	39.366	157.46	24-28	27-31
350	35.291	141.16	33.742	134.97	23-27	26-30
400	30.881	123.52	29.525	118.10	22-26	25-29
450	27.449	109.80	26.244	104.98	20-24	23-27
500	24.704	98.817	23.620	94.479	20-24	23-27
550	22.458	89.832	21.472	85.889	19-23	22-26
600	20.586	83.345	19.683	79.730	19-23	22-26
650	19.004	76.016	18.170	72.679	18-22	21-25
700	17.646	70.584	16.871	67.486	18-22	21-25
750	16.468	65.874	15.745	62.982	18-22	21-25
800	15.440	61.766	14.762	59.055	18-22	21-25
850	14.532	58.128	13.894	55.577	17-21	20-24
900	13.724	54.897	13.122	52.487	17-21	20-24
950	13.002	52.009	12.431	49.726	17-21	20-24
1000	12.352	49.409	11.810	47.240	16-20	19-23
1050	11.764	47.055	11.247	44.989	16-20	19-23
1100	..229	44.918	10.737	42.946	16-20	19-23
1150	10.741	42.964	10.270	41.078	15-19	18-22
1200	10.2936	41.174	9.8418	39.367	15-19	18-22
1250	9.8817	39.527	9.4479	37.792	14-18	17-21
1300	9.5016	38.006	9.0845	36.338	14-18	17-21
1350	9.1497	37.599	8.7480	35.992	13-17	16-20
1400	8.8229	36.292	8.4356	34.743	13-17	16-20
1450	8.5188	34.075	8.1449	32.579	12-16	15-19
1500	8.2347	32.938	7.8732	31.493	12-16	15-19
2000	6.1761	24.704	5.9050	23.619	10-14	13-17
2500	4.9409	19.764	4.7240	18.896	9-13	12-16
3000	4.1174	16.469	3.9366	15.746	8-12	11-15

AWG Wire Gauge Calculator / Converter

admin — Tue, 21 Jun 2011 09:59:03 +0000

Convert from inches or millimeters to AWG

AWG Number	Ø [Inch]	Ø [mm]	Ø [mm²]
6/0 = 000000	0.580	14.73	170.30
5/0 = 00000	0.517	13.12	135.10
4/0 = 0000	0.460	11.7	107
3/0 = 000	0.410	10.4	85.0
2/0 = 00	0.365	9.26	67.4
1/0 = 0	0.325	8.25	53.5
1	0.289	7.35	42.4
2	0.258	6.54	33.6
3	0.229	5.83	26.7
4	0.204	5.19	21.1
5	0.182	4.62	16.8
6	0.162	4.11	13.3
7	0.144	3.66	10.5
8	0.128	3.26	8.36
9	0.114	2.91	6.63
10	0.102	2.59	5.26
11	0.0907	2.30	4.17
12	0.0808	2.05	3.31
13	0.0720	1.83	2.62
14	0.0641	1.63	2.08
15	0.0571	1.45	1.65
16	0.0508	1.29	1.31
17	0.0453	1.15	1.04
18	0.0403	1.02	0.823
19	0.0359	0.912	0.653
20	0.0320	0.812	0.518
21	0.0285	0.723	0.410
22	0.0253	0.644	0.326
23	0.0226	0.573	0.258
24	0.0201	0.511	0.205
25	0.0179	0.455	0.162
26	0.0159	0.405	0.129
27	0.0142	0.361	0.102
28	0.0126	0.321	0.0810
29	0.0113	0.286	0.0642
30	0.0100	0.255	0.0509
31	0.00893	0.227	0.0404
32	0.00795	0.202	0.0320
33	0.00708	0.180	0.0254
34	0.00631	0.160	0.0201
35	0.00562	0.143	0.0160
36	0.00500	0.127	0.0127
37	0.00445	0.113	0.0100
38	0.00397	0.101	0.00797
39	0.00353	0.0897	0.00632
40	0.00314	0.0799	0.00501

Heating Element Calculations & Ohm’s Law

admin — Mon, 20 Jun 2011 16:38:40 +0000

Heating Element Calculations

In order to make the basic calculations for the design of heating elements the following formulas, known as Ohm’s Law, are essential:

Volts = Amperes x Ohms Calculator

Watts = Volts x Amperes Calculator

Watts = (Amperes) 2 x Ohms Calculator

Useful Coil Formulas

Length of one turn of wire = π (Outside coil dia. - wire dia.) Calculator

Number of turns of wire per inch of coil = 1 / Wire Dia. Calculator

Length of wire in 1″ of closed coil = π(Outside coil dia. - Wire dia.) / Wire dia. Calculator Calculator

Resistance per inch of closed coil = π(Outside coil dia. - Wire dia.) (resistance / ft. of wire) / 12 (Wire dia.) Calculator

Length of coil = Total resistance of coil / Resistance per inch of closed coil Calculator

Combining the above formulas given above we get the complete formula for coil calculations.

Length of Coil = Coil Resistance x Wire Dia. / .262 (Coil Outside Dia. - Wire Dia.) (Resistance / FT. of Wire Used) Calculator

Wire Resistance = (Ohms / Cir. Mil. Ft.) / Diameter² (expressed in mils.) Calculator

Strip & Ribbon Resistance = (Ohms / Sq. Mil. Ft.) / Thickness (Mils.) x Width (Mils.) x Correction Factor Calculator

Wire Wt. = πr² x Length x Lbs./Cubic Inch Calculator

Strip Wt. = Thickness x Width x Length x Lbs./Cubic Inch Calculator

Ohms/Sq. Mil. Ft. = Ohms/Cir. Mil. Ft. x .7854 Calculator

Wire Journal International

admin — Mon, 20 Jun 2011 15:39:44 +0000

Pelican Wire Co. discusses social responsibility and it’s commitment to sustainability in Wire Journal International, Page 68.

Social responsibility is a big factor in a lot of our opera- tional decisions. We also get peer pressure from our “greener” customers, such as one that made a die to remold their PEX bleed out scrap into packaging materi- als for their product. Reduction of VOCs in our saturation and enameling processes has been our most conscious decision in this regard.
The solvent-based prod- ucts have more history and are easier to work with (shorter drying times, better adhesion, etc.) but they are not very environmentally friendly. We spend a lot of time finding water-based sub- stitutes and adapting them to our products whenever possible.

Often times “green” may refer to RoHS and REACH compliance. Since the advent of RoHS, the Union Court has new rulings, such as the list of hazardous substances changes. For instance, Deca-BDE (decabromodiphenylether) was recently put back on the list. There are still a number of companies who purchase and use this FR component in their product (knowingly). We, however, do not. Brad Burris, Pelican Wire Company, Inc.

Wire Journal QA Article

What types of thermocouple wire do you carry?

admin — Mon, 20 Jun 2011 13:30:57 +0000

We stock bare and insulated thermocouple wire in ANSI Type J, K, T, and E calibrations with traceability to NIST. We supply thermocouple wire as small as 40 AWG. Insulated thermocouple wire can be custom built to the customers’ exact specifications including calibration type, wire gauge, and individual calibration requirements. We supply bulk insulated thermocouple wire to many instrumentation manufacturers for use in their products. We also make insulated thermocouple wire for use from -400°F to over 2,200°F. Learn more on our thermocouple wire page.
